Kneader Mixer
A kneader is a device specifically designed for the mixing and processing of high-viscosity and elastomeric materials. It is widely used in industries such as chemical engineering, food, medicine, and rubber.
Definition: Through the differential rotation of two blades (usually in the form of Σ or Z) to generate shear force, it enables processes such as kneading, mixing, and vulcanization of the materials.
Working principle: The two blades rotate at different speeds (for example, 42/28 revolutions per minute), creating a combined axial compression and radial shearing motion, ensuring thorough mixing with no dead zones.
Main types and characteristics：
|
Type |
Applicable Scenarios |
Core Features |
|
ordinary type |
Basic mixed demand (such as food gel base) |
Simple structure, low cost, supports electric heating or water cooling |
|
Vacuum type |
Production of silicone rubber and sealant |
The vacuum level ranges from -0.096 to -0.1 MPa, which prevents the material from oxidizing and enhances the purity. |
|
High-temperature heating type |
Materials that require high-temperature reactions (such as hot melt adhesives) |
Supports heat transfer oil/steam heating, with precise temperature control. |
|
Multi-purpose type |
Cross-industry universal (cosmetics, battery pastes, etc.) |
Modular design, with options for hydraulic cylinder discharge, screw extrusion, and other types of discharge methods. |
Key Structures and Configurations:
Material: Components in contact with the material (cylinder body, blades) are mostly made of SUS304/316L stainless steel, which is corrosion-resistant.
Transmission System: Synchronous gear reducer + variable frequency speed control, ensuring smooth operation and low noise.
Temperature Control System: Double-layer design, supporting multiple modes such as electric heating, steam, and water cooling.
Discharge Method: Hydraulic cylinder flipping (large capacity), screw extrusion (high viscosity materials), ball valve (continuous production)
Typical application fields:
Chemical industry: Mixing of silicone rubber, sealant, and glass adhesive
Food industry: Uniform mixing of chewing gum and gelatin-based candies
Pharmaceutical industry: Efficient stirring of ointments and preparations
New energy industry: Dispersion treatment of battery pastes
Purchase Suggestions:
Capacity Selection: Laboratory use: 5L - 50L; Industrial grade: 100L - 3000L
Additional Functions: Optional with PLC control, vacuum system or waste gas treatment module according to requirements
v Industry Frontline News:
The 2025 South China Silicon Industry Conference will be held in Shenzhen on October 29th. It focuses on the upgrading of silicone rubber kneading technology and green manufacturing, and plans to showcase new low-energy consumption kneading equipment.
